Machine DESCRIPTION

The AconityMIDI is Aconity3D’s approach for a flexible production system. Equipped with an optional second process chamber, this system allows for parallelizing setup times while the main system is still producing. Additionally, process monitoring or high- temperature preheating of up to 1200 °C is also available for this system.

The AconityMIDI is also available as DUAL-Laser system for further maximized productivity.

Additionally, the AconityMIDI may be equipped with the unique Vacuum option and Micro-LBM configuration.

Technical SPECIFICATIONS

AconityMIDI is the ideal combination of flexibilty and productivity.

Build space

Ø 170 mm x H 200 mm

Laser Confi­guration

Up to 2x Single Mode 400 W / 500 W / 700 W / 1000 W

Optics confi­guration / Spot size

F-Theta / 80 μm
3D Scanning / 80 – 500 μm

Process chamber

Exchangeable with optional
external process preparation
station

Process monitoring options

Coaxial pyrometer
Coaxial high speed CMOS

Preheating temp / build space

500 °C / Ø 170 mm x H 150 mm
800 °C / Ø 100 mm x H 150 mm
1200 °C / Ø 70 mm x H 150 mm

Layer thickness

Down to 10 µm

Max scan speed

12 m/s

Inert gas type / pressure

Argon 4.6 / 6 bar
Nitrogen / 6 bar

Inert gas consumption

< 5 l/min during process
< 30 l/min during purging
0 - 5 l/min for vacuum

Residual oxygen content

< 100 ppm

Pressurized air type / pressure

ISO 8573-1:2010 [1:4:1] / 6 bar

Pressurized air consumption

< 50 l/min

Machine Dimensions (W x D X H)

2450 mm x 1500 mm x 2320 mm

Machine weight w/o powder

1450 kg

In the News... ACONITY INLINE PROCESS-MONITORING

Aconity3D is one of the leading providers of in-process monitoring systems for laser-based 3D printing of metals (L-PBF).
The process monitoring tool allows for in-line identification of the influence of changed process parameters on the to-be-built part.

The featured video shows a comparisson of the size of the melt pool for contour scans of two consecutively scanned layers.

Accordingly, the influence of changed laser processing parameters on the size of the melt pool may be identified.
The featured video is part of Aconity3D’s ongoing effort towards increasing process understanding in the field of Laser-Powder Bed Fustion (L-PBF) with the ultimate goal of qualifying AM of metals for series applications
Inline process monitoring is available for all Aconity systems. Try our online machine configurator to configure your individual system now: https://configurator.aconity3d.com/EN/units/AconityMIDI
